In stock
SP20-SQ 4-hole flange aviation connector — IP68
From $3.94from 50 pcs per model. Volume breaks quoted at 500 / 1,000 / 5,000 pcs.
MOQ 50 pcGold-plated contacts11 variants
SP20-SQ is a sealed circular aviation connector with 4-hole flange mounting. Offered in 11 contact counts from 1 to 14. IP68 sealed. Gold-plated copper contacts. Priced per piece EXW from Yueqing, 50 pcs minimum per model.
| Configuration | Stock | EXW / pc |
|---|---|---|
| SP20 · 1-pin 4-hole flange | 100 | $3.94 |
| SP20 · 2-pin 4-hole flange | 100 | $4.20 |
| SP20 · 3-pin 4-hole flange | 100 | $4.65 |
| SP20 · 4-pin 4-hole flange | 100 | $5.25 |
| SP20 · 5-pin 4-hole flange | 100 | $5.55 |
| SP20 · 6-pin 4-hole flange | 100 | $5.63 |
| SP20 · 7-pin 4-hole flange | 100 | $5.78 |
| SP20 · 9-pin 4-hole flange | 100 | $5.97 |
| SP20 · 10-pin 4-hole flange | 100 | $6.00 |
| SP20 · 12-pin 4-hole flange | 100 | $6.15 |
| SP20 · 14-pin 4-hole flange | 100 | $6.72 |
Specifications
| Electrical | |
|---|---|
| Ingress protection | IP68 |
| Rated current | 5–25 A |
| Rated voltage | 250–380 V |
| Contact plating | Gold-plated copper |
| Mechanical | |
| Mounting | 4-hole flange |
| Contacts | 1–14 pins |
| Identification | |
| Series | SP20 |
| Configuration | plug and socket set |
